SPECTRAL DMA-90s Power-Amplifier
Power Output: (continuous)Stereo:
@ 8 ohms – 100 Watts RMS,
@ 4 ohms – 200 Watts RMS
Bridged:
 @ 8 ohms – 180 Watts RMS
 @ 4 ohms – 250 Watts
Output Current: 22 Amps per channel
Frequency Response:
0.1 dB, DC-150 KHz 1 dB, DC-1 MHz3 dB, DC-1.8 MHz
Distortion:
Static: Less than 0.015  @ 100 Watts RMS/8 ohms
Dynamic: 8 Tone Cluster Test 20 KHz
@ 500 Hz separation; 0.01% 8 ohms; 0.015% 4 ohms
Speed:
Rise Time: Less than 300 nanoseconds
Settling Time: 1.5 microseconds to -40dB
Slew Rate: 1000 volts/microsecond
Noise:
Signal to Noise: 97dB unweighted
Input:
Impedence: 10K ohms in parallel with 100 pf
Sensitivity: 1.5 volts/nominal output
Size and Weight:
Dimensions: 48cm W x 6.5cm H x 39.35cm D
Weight: 20 lbs 9.1 KG Ne
